Rail-Assisted
Semi-Automatic
Rail-guided throughput with operator supervision on mid-size ground-mount plants.
The SUNAIROBOT Semi-Automatic robot is a rail-guided, operator-supervised system for mid-size ground-mount plants that need higher throughput than a portable unit.
Once table-edge rails are in place, the robot travels rows with consistent brush pressure while an operator supervises start, stop, and transfers. It is the practical middle ground between rooftop Lift & Shift and fully autonomous utility-scale fleets.
Overview
What it is, where it fits,
what problem it solves
Best for: Mid-size ground-mount.
Key Benefits
Why O&M teams pick
Semi-Automatic
Rail-guided path
Table-edge rails keep coverage consistent along the row.
Higher throughput
Faster than portable Lift & Shift on long ground-mount tables.
Operator supervision
Start, stop, and transfers stay under O&M control.
Repeatable cadence
The same pass every cycle — not ad-hoc mopping.
Dry and wet options
Match Rajasthan/Gujarat dust or wetter soiling.
Mid-size plant fit
Sized for commercial ground-mount, not only rooftops or 100 MW+ parks.
Technical Specifications
Working data for site sizing
| Model | SR-01 — Semi-Automatic (supervised) |
|---|---|
| Operating modes | Manual / Semi-Automatic / Automatic |
| Controls | Forward · Reverse · Stop · On/Off |
| Cleaning speed | Up to 20 m/min |
| Cleaning method | Dry brush (waterless) + screw mechanism |
| Brush | Soft PBT brush |
| Motor | PMDC · 3000 RPM · 120 W · 6.67 A |
| Drive | High-torque geared motor · 6-wheel drive · 24 VDC |
| Battery | LiFePO₄ · 29.5 VDC · 18 Ah · ~3.3 h run time |
| Charging | 29.5 VDC · 5–9 A · ~3.5 h |
| Body | Aluminium alloy |
| Protection | Robot IP65 / Motor IP54 |
| Weight | < 47 kg |
| Safety | 2 / 4 proximity sensors |
| Install angle | Up to 30° tilt |
| Operating temp | −10 °C to +60 °C |
Final names, drawings, and certified specs follow client Drive/brochure assets. Values here are working labels for site fit — not a substitute for an approved datasheet.
How It Works
From survey to cleaning cadence
1. Survey table geometry
We measure row length, tilt, tracker vs fixed, and water so the rail and robot match the plant.
2. Install rails
Table-edge guides go in. Operators are trained on load, start, and transfer.
3. Supervised passes
The robot runs the row; the crew handles table-to-table moves and exceptions.
4. Cadence and spares
Lock a weekly or soiling-driven cycle and keep brushes/spares on site.
Best For / Applications
Where Semi-Automatic belongs
- Mid-size ground-mount solar plants
- Fixed-tilt commercial parks
- Sites stepping up from portable robots
- Plants not yet ready for fully unmanned fleets
Gallery
Product and operating views
Related Projects
Semi-Automatic in the field
Semi-Automatic
Gujarat · 120 MW
Semi-Automatic
Gujarat · 50 MW
Downloads
Brochure and spec sheet
Approved PDF datasheets and manuals ship with the client Drive pack. Until those files are published, request the Semi-Automatic spec sheet with your site MW and we will send the current pack.
FAQ
Semi-Automatic questions
Is this the same as Fully Automatic?
No. Semi-Automatic is rail-guided and operator-supervised. Fully Automatic adds scheduled autonomy and fleet telemetry.
Do we need rails on every table?
Rails are part of this product. Share layout drawings and we mark which tables get guided path first.
Can it run dry in Gujarat/Rajasthan?
Yes. Dry brush is the default for arid soiling; wet is optional.
How do we demo?
Share MW, tracker vs fixed, and a site photo. We confirm Semi-Automatic vs Lift & Shift or Fully Automatic.
